AVAILABLE MODELS AND ORDER CODES
CABLE ORDER CODES
SG4 BODY REFLECTOR BASE
[ SG4-RBx-xxx-OO-E ]
Order Number
SG4 BODY REFLECTOR MUTING
[ SG4-RBx-xxx-OO-W ]
Order Number
ACTIVE SIDE
SG4-RB2-050-OO-E
957951000
LINEAR (WITHOUT MUTING ARMS)
SG4-RB3-080-OO-E
957951010
SG4-RB2-050-OO-W
957951030
SG4-RB4-090-OO-E
957951190
SG4-RB3-080-OO-W
957951040
SG4-RB4-120-OO-E
957951020
SG4-RB4-090-OO-W
957951180
---
---
SG4-RB4-120-OO-W
957951050
---
---
WITH T MUTING ARMS
---
---
SG4-RB2T-050-OO-W
957951080
---
---
SG4-RB3T-080-OO-W
957951090
---
---
WITH L MUTING ARMS
---
---
SG4-RB2L-050-OO-W
957951060
---
---
SG4-RB3L-080-OO-W
957951070
PASSIVE SIDE
SG4 BODY REFLECTOR BASE
[ SG4-RDBx]
[ SG4-RDBx-xxx]
Order code
SG4 BODY BIG MUTING
[ SG4-RDBx]
[ SG4-RDBxL/T]
Order code
SG4-RDB2
957951100
LINEAR (WITHOUT MUTING ARMS)
SG4-RDB3
957951110
SG4-RDB2
957951100
SG4-RDB4-090
957951170
SG4-RDB3
957951110
SG4-RDB4-120
957951120
SG4-RDB4-090
957951170
---
---
SG4-RDB4-120
957951120
---
---
WITH T MUTING ARMS
---
---
SG4-RDB2T
957951150
---
---
SG4-RDB3T
957951160
---
---
WITH L MUTING ARMS
---
---
SG4-RDB2L
957951130
---
---
SG4-RDB3L
957951140
IMPORTANT NOTES
1) Active and passive sides must be ordered separately
2) Brackets are not included in the SG4 BODY REFLECTOR packing and must be ordered separately (see accessories table)
ACTIVE UNIT
(MAIN CONNECTOR)
Length (m)
Order code
SG4 BODY REFLECTOR BASE
[ SG4-RBx-xxx-OO-E ]
CS-A1-06-U-03
3
95ASE1220
CS-A1-06-U-05
5
95ASE1230
CS-A1-06-U-10
10
95ASE1240
CS-A1-06-U-15
15
95ASE1250
CS-A1-06-U-25
25
95ASE1260
CS-A1-06-U-50
50
95A252710
SG4 BODY REFLECTOR MUTING
[ SG4-RBx-xxx-OO-W ]
CS-A1-10-U-03
3
95A252720
CS-A1-10-U-05
5
95A252730
CS-A1-10-U-10
10
95A252740
CS-A1-10-U-15
15
95A252750
CS-A1-10-U-25
25
95A252760
CS-A1-10-U-50
50
95A252770
ACTIVE UNIT
(SECONDARY CONNECTOR)
Length (m)
Order code
SG4 BODY REFLECTOR MUTING
[ SG4-RBx-xxx-OO-W ]
CS-A1-03-U-03
3
95ASE1170
CS-A1-03-U-05
5
95ASE1180
CS-A1-03-U-10
10
95ASE1190
CS-A1-03-U-15
15
95ASE1200
CS-A1-03-U-25
25
95ASE1210
CS-A1-03-U-50
50
95A252700
NOTES
All cables have axial connectors
