56
STANDARD Vac
FLUSH
M12 conn
cable
NOMINAL SWITCHING DISTANCE
2 mm
2 mm
10-30 Vdc
PNP/NPN
NO-NC
4 wires
---
---
order No.
---
---
10-30 Vdc
PNP
NO
3 wires
---
---
order No.
---
---
10-30 Vdc
PNP
NC
3 wires
---
---
order No.
---
---
10-30 Vdc
NPN
NO
3 wires
---
---
order No.
---
---
10-30 Vdc
NPN
NC
3 wires
---
---
order No.
---
---
10-30 Vdc
PNP
NO-NC
3 wires
---
---
order No.
---
---
10-30 Vdc
NPN
NO-NC
3 wires
---
---
order No.
---
---
10-30 Vdc
NO-NC
2 wires
---
---
order No.
---
---
20-250 Vac/Vdc NO
2 wires
---
---
order No.
---
---
20-250 Vac/Vdc NC
2 wires
---
---
order No.
---
---
20-250 Vac/Vdc NO
2/3wires
IS-12-A15-S2
IS-12-A15-03
order No.
95B060690
95B060680
Analog 0-20mA -
3 wires
---
---
order No.
---
---
5+24 Vdc
NAMUR 2 wires
---
---
order No.
---
---
Nominal Voltage
20+250 Vac (50,60 Hz)
20+250 Vac (50,60 Hz)
Residual Ripple
< 10%
< 10%
Hysteresis
< 10%
< 10%
Max. Output Current
500 mA, inrush:1,5A
500 mA, inrush:1,5A
Min. Output Current
20 mA
20 mA
Residual Current
< 0,7 mA
< 0,7 mA
Voltage Drop
< 4 V (I=100mA)
< 4 V (I=100mA)
Operation Led
Yellow
Yellow
Switching Frequency
25 Hz
25 Hz
Start Up Delay
< 300 ms
< 300 ms
Repeability
5%
5%
Short Circuit Protection
Present (self-resetting)
Present (self-resetting)
Electric Protection
Against polarity reversal
inductive loads
Against polarity reversal
inductive loads
Temperature Limit
(-25 ... +70 °C)
(-25 ... +70 °C)
Protection Degree
IP67
IP67
Cable Length
---
2 m
Cable Section
---
2 x 0,25 mm²
Housing Material
Nickel-plated brass
Nickel-plated brass
Weight - Cable Output
---
145g
Weight - M12 Connector Output
95g
---
INDUCTIVE AC m12
