52
FIELD IMMUNE STAINLESS STEEL
FLUSH
NON FLUSH
M12 conn
M12 conn
NOMINAL SWITCHING DISTANCE
2 mm
4 mm
10-30 Vdc
PNP/NPN
NO-NC
4 wires
---
---
order No.
---
---
10-30 Vdc
PNP
NO
3 wires
IS-F12-S1-S2
IS-F12-T1-S2
order No.
95B065360
95B065370
10-30 Vdc
PNP
NC
3 wires
---
---
order No.
---
---
10-30 Vdc
NPN
NO
3 wires
---
---
order No.
---
---
10-30 Vdc
NPN
NC
3 wires
---
---
order No.
---
---
10-30 Vdc
PNP
NO-NC
3 wires
---
---
order No.
---
---
10-30 Vdc
NPN
NO-NC
3 wires
---
---
order No.
---
---
10-30 Vdc
NO-NC
2 wires
---
---
order No.
---
---
20-250 Vac/Vdc NO
2 wires
---
---
order No.
---
---
20-250 Vac/Vdc NC
2 wires
---
---
order No.
---
---
20-250 Vac/Vdc NO
2/3wires
---
---
order No.
---
---
Analog 0-20mA -
3 wires
---
---
order No.
---
---
5+24 Vdc
NAMUR 2 wires
---
---
order No.
---
---
Nominal Voltage
10-30 Vdc
10-30 Vdc
Residual Ripple
< 10%
< 10%
Hysteresis
< 15%
< 15%
Max. Output Current
200 mA
200 mA
Min. Output Current
< 10mA
< 10mA
Residual Current
< 0,1 mA
< 0,1 mA
Voltage Drop
< 1,5V
< 1,5V
Operation Led
Present
Present
Switching Frequency
2000 Hz
1000 Hz
Start Up Delay
< 0,1 ms
< 0,1 ms
Repeability
< 1%
< 1%
Short Circuit Protection
Present (self-resetting)
Present (self-resetting)
Electric Protection
Against polarity reversal
inductive loads
Against polarity reversal
inductive loads
Temperature Limit
(-25 ... +70 °C)
(-25 ... +70 °C)
Protection Degree
IP67
IP67
Cable Length
---
---
Cable Section
---
---
Housing Material
Stainless-Steel
Stainless-Steel
Weight - Cable Output
---
---
Weight - M12 Connector Output
25g
23g
weld field immune m12
