42
SHORT STAINLESS STEEL
FLUSH
NON FLUSH
M12 conn
M12 conn
NOMINAL SWITCHING DISTANCE
5 mm
8 mm
10-30 Vdc
PNP/NPN
NO-NC
4 wires
---
---
order No.
---
---
10-30 Vdc
PNP
NO
3 wires
IS-18-M1-S2
IS-18-N1-S2
order No.
95B060320
95B060360
10-30 Vdc
PNP
NC
3 wires
IS-18-M2-S2
IS-18-N2-S2
order No.
95B060330
95B060370
10-30 Vdc
NPN
NO
3 wires
IS-18-M3-S2
IS-18-N3-S2
order No.
95B060340
95B060380
10-30 Vdc
NPN
NC
3 wires
IS-18-M4-S2
IS-18-N4-S2
order No.
95B060350
95B060390
10-30 Vdc
PNP
NO-NC
3 wires
---
---
order No.
---
---
10-30 Vdc
NPN
NO-NC
3 wires
---
---
order No.
---
---
10-30 Vdc
NO-NC
2 wires
---
---
order No.
---
---
20-250 Vac/Vdc NO
2 wires
---
---
order No.
---
---
20-250 Vac/Vdc NC
2 wires
---
---
order No.
---
---
20-250 Vac/Vdc NO
2/3wires
---
---
order No.
---
---
Analog 0-20mA -
3 wires
---
---
order No.
---
---
5+24 Vdc
NAMUR 2 wires
---
---
order No.
---
---
Nominal Voltage
10-30 Vdc (-15/10%)
10-30 Vdc (-15/10%)
Residual Ripple
< 10%
< 10%
Hysteresis
< 10%
< 10%
Max. Output Current
200 mA
200 mA
Min. Output Current
---
---
Residual Current
< 10 mA
< 10 mA
Voltage Drop
< 1,8 V (I=100mA)
< 1,8 V (I=100mA)
Operation Led
Yellow
Yellow
Switching Frequency
1000 Hz
1000 Hz
Start Up Delay
< 50 ms
< 50 ms
Repeability
< 3%
< 3%
Short Circuit Protection
Present (self-resetting)
Present (self-resetting)
Electric Protection
Against polarity reversal
inductive loads
Against polarity reversal
inductive loads
Temperature Limit
(-25 ... +60 °C)
(-25 ... +60 °C)
Protection Degree
IP67
IP67
Cable Length
---
---
Cable Section
---
---
Housing Material
Stainless-Steel
Stainless-Steel
Weight - Cable Output
---
---
Weight - M12 Connector Output
95g
95g
STAINLESS STEEL m18
