STANDARD
STANDARD X2
FLUSH
FLUSH
M8 conn
cable
cable
NOMINAL SWITCHING DISTANCE
0,8 mm
0,8 mm
1,5 mm
10-30 Vdc
PNP/NPN
NO-NC
4 wires
---
---
---
order No.
---
---
---
10-30 Vdc
PNP
NO
3 wires
IS-05-A1-S1
IS-05-A1-03
---
order No.
95B061051
95B061041
---
10-30 Vdc
PNP
NC
3 wires
---
---
---
order No.
---
---
---
10-30 Vdc
NPN
NO
3 wires
IS-05-A3-S1
IS-05-A3-03
IS-05-E3-03
order No.
95B061031
95B061021
95B065400
10-30 Vdc
NPN
NC
3 wires
IS-05-A4-03
---
order No.
95B065420
---
10-30 Vdc
PNP
NO-NC
3 wires
---
---
---
order No.
---
---
---
10-30 Vdc
NPN
NO-NC
3 wires
---
---
---
order No.
---
---
---
10-30 Vdc
NO-NC
2 wires
---
---
---
order No.
---
---
---
20-250 Vac/Vdc NO
2 wires
---
---
---
order No.
---
---
---
20-250 Vac/Vdc NC
2 wires
---
---
---
order No.
---
---
---
20-250 Vac/Vdc NO
2/3wires
---
---
---
order No.
---
---
---
Analog 0-20mA -
3 wires
---
---
---
order No.
---
---
---
5+24 Vdc
NAMUR 2 wires
---
---
---
order No.
---
---
---
Nominal Voltage
10-30 Vdc (-15/10%)
10-30 Vdc (-15/10%)
10-30 Vdc (-15/10%)
Residual Ripple
< 10%
< 10%
< 10%
Hysteresis
< 15%
< 15%
< 15%
Max. Output Current
100 mA
100 mA
100 mA
Min. Output Current
---
---
---
Residual Current
< 0,01 mA
< 0,01 mA
< 0,01 mA
Voltage Drop
< 1,5V
< 1,5V
< 1,5V
Operation Led
Yellow
Yellow
Yellow
Switching Frequency
2000 Hz
2000 Hz
2000 Hz
Start Up Delay
---
---
---
Repeability
< 1%
< 1%
---
Short Circuit Protection
Present (self-resetting)
Present (self-resetting)
Present (self-resetting)
Electric Protection
Against polarity reversal
inductive loads
Against polarity reversal
inductive loads
Against polarity reversal
inductive loads
Temperature Limit
(-25 ... +70 °C)
(-25 ... +70 °C)
(-25 ... +70 °C)
Protection Degree
IP67
IP67
IP67
Cable Length
---
2 m (PUR)
2 m (PUR)
Cable Section
---
3x 0,15 mm²
3x 0,15 mm²
Housing Material
Stainless-Steel
Stainless-Steel
Stainless-Steel
Weight - Cable Output
---
25g
25g
Weight - M12 Connector Output
14g
---
---
STAINLESS STEEL m5
STAINLESS
STEEL
