30
SHORT X2
FLUSH
NON FLUSH
M12 conn
cable
M12 conn
cable
NOMINAL SWITCHING DISTANCE
15mm
15mm
20 mm
20 mm
10-30 Vdc
PNP/NPN
NO-NC
4 wires
IS-30-G0-S2
IS-30-G0-03
IS-30-H0-S2
IS-30-H0-03
order No.
95B064500
95B063861
95B064520
95B064480
10-30 Vdc
PNP
NO
3 wires
IS-30-G1-S2
IS-30-G1-03
IS-30-H1-S2
IS-30-H1-03
order No.
95B063691
95B063681
95B063771
95B063761
10-30 Vdc
PNP
NC
3 wires
IS-30-G2-S2
IS-30-G2-03
IS-30-H2-S2
IS-30-H2-03
order No.
95B063711
95B063701
95B063791
95B063781
10-30 Vdc
NPN
NO
3 wires
IS-30-G3-S2
IS-30-G3-03
IS-30-H3-S2
IS-30-H3-03
order No.
95B063651
95B063641
95B063731
95B063721
10-30 Vdc
NPN
NC
3 wires
IS-30-G4-S2
IS-30-G4-03
IS-30-H4-S2
IS-30-H4-03
order No.
95B063671
95B063661
95B063751
95B063741
10-30 Vdc
PNP
NO-NC
3 wires
IS-30-G5-S2
IS-30-G5-03
IS-30-H5-S2
IS-30-H5-03
order No.
95B063831
95B063821
95B064450
95B064420
10-30 Vdc
NPN
NO-NC
3 wires
IS-30-G6-S2
IS-30-G6-03
IS-30-H6-S2
IS-30-H6-03
order No.
95B064430
95B064400
95B064440
95B064410
10-30 Vdc
NO-NC
2 wires
IS-30-G9-S2
IS-30-G9-03
IS-30-H9-S2
IS-30-H9-03
order No.
95B064580
95B064540
95B064600
95B064560
20-250 Vac/Vdc NO
2 wires
---
---
---
---
order No.
---
---
---
---
20-250 Vac/Vdc NC
2 wires
---
---
---
---
order No.
---
---
---
---
20-250 Vac/Vdc NO
2/3wires
---
---
---
---
order No.
---
---
---
---
Analog 0-20mA -
3 wires
---
---
---
---
order No.
---
---
---
---
5+24 Vdc
NAMUR 2 wires
---
---
---
---
order No.
---
---
---
---
Nominal Voltage
10-30 Vdc (-15/10%)
10-30 Vdc (-15/10%)
10-30 Vdc (-15/10%)
10-30 Vdc (-15/10%)
Residual Ripple
< 10%
< 10%
< 10%
< 10%
Hysteresis
< 10%
< 10%
< 10%
< 10%
Max. Output Current
200 mA
200 mA
200 mA
200 mA
Min. Output Current
---
---
---
---
Residual Current
< 10 mA
< 10 mA
< 10 mA
< 10 mA
Voltage Drop
< 1,2 V (I=100mA)
< 1,2 V (I=100mA)
< 1,2 V (I=100mA)
< 1,2 V (I=100mA)
Operation Led
Yellow
Yellow
Yellow
Yellow
Switching Frequency
200 Hz
200 Hz
200 Hz
200 Hz
Start Up Delay
< 75 ms
< 75 ms
< 75 ms
< 75 ms
Repeability
< 3%
< 3%
< 3%
< 3%
Short Circuit Protection
Present (self-resetting)
Present (self-resetting)
Present (self-resetting)
Present (self-resetting)
Electric Protection
Against polarity reversal
inductive loads
Against polarity reversal
inductive loads
Against polarity reversal
inductive loads
Against polarity reversal
inductive loads
Temperature Limit
(-25 ... +70 °C)
(-25 ... +70 °C)
(-25 ... +70 °C)
(-25 ... +70 °C)
Protection Degree
IP67
IP67
IP67
IP67
Cable Length
---
2 m
---
2 m
Cable Section
---
3 x 0,25 mm²
---
3 x 0,25 mm²
Housing Material
Nickel-plated brass
Nickel-plated brass
Nickel-plated brass
Nickel-plated brass
Weight - Cable Output
---
210 g
---
210 g
Weight - M12 Connector Output
170 g
---
170 g
---
basic m30
