20
STANDARD
FLUSH
NON FLUSH
M12 conn
cable
M12 conn
cable
NOMINAL SWITCHING DISTANCE
2 mm
2 mm
4 mm
4 mm
10-30 Vdc
PNP/NPN
NO-NC
4 wires
IS-12-A0-S2
IS-12-A0-03
IS-12-C0-S2
IS-12-C0-03
order No.
95B064060
95B064030
95B064080
95B064040
10-30 Vdc
PNP
NO
3 wires
IS-12-A1-S2
IS-12-A1-03
IS-12-C1-S2
IS-12-C1-03
order No.
95B061251
95B061241
95B061651
95B061641
10-30 Vdc
PNP
NC
3 wires
IS-12-A2-S2
IS-12-A2-03
IS-12-C2-S2
IS-12-C2-03
order No.
95B061281
95B061271
95B061681
95B061671
10-30 Vdc
NPN
NO
3 wires
IS-12-A3-S2
IS-12-A3-03
IS-12-C3-S2
IS-12-C3-03
order No.
95B061191
95B061181
95B061591
95B061581
10-30 Vdc
NPN
NC
3 wires
IS-12-A4-S2
IS-12-A4-03
IS-12-C4-S2
IS-12-C4-03
order No.
95B061221
95B061211
95B061621
95B061611
10-30 Vdc
PNP
NO-NC
3 wires
---
---
---
---
order No.
---
---
---
---
10-30 Vdc
NPN
NO-NC
3 wires
---
---
---
---
order No.
---
---
---
---
10-30 Vdc
NO-NC
2 wires
IS-12-A9-S2
IS-12-A9-03
IS-12-C9-S2
IS-12-C9-03
order No.
95B063931
95B064100
95B064140
95B064110
20-250 Vac/Vdc NO
2 wires
---
---
---
---
order No.
---
---
---
---
20-250 Vac/Vdc NC
2 wires
---
---
---
---
order No.
---
---
---
---
20-250 Vac/Vdc NO
2/3wires
---
---
---
---
order No.
---
---
---
---
Analog 0-20mA -
3 wires
---
---
---
---
order No.
---
---
---
---
5+24 Vdc
NAMUR 2 wires
---
---
---
---
order No.
---
---
---
---
Nominal Voltage
10-30 Vdc (-15/10%)
10-30 Vdc (-15/10%)
10-30 Vdc (-15/10%)
10-30 Vdc (-15/10%)
Residual Ripple
< 10%
< 10%
< 10%
< 10%
Hysteresis
< 10%
< 10%
< 10%
< 10%
Max. Output Current
200mA; 100 mA (2wires)
200mA; 100 mA (2wires)
200mA; 100 mA (2wires)
200mA; 100 mA (2wires)
Min. Output Current
> 1,6 mA (2wires)
> 1,6 mA (2wires)
> 1,6 mA (2wires)
> 1,6 mA (2wires)
Residual Current
< 10mA; < 1,6 mA (2wires)
< 10mA; < 1,6 mA (2wires)
< 10mA; < 1,6 mA (2wires)
< 10mA; < 1,6 mA (2wires)
Voltage Drop
< 1,8V; < 6,5 V (2wires)
< 1,8V; < 6,5 V (2wires)
< 1,8V; < 6,5 V (2wires)
< 1,8V; < 6,5 V (2wires)
Operation Led
Yellow
Yellow
Yellow
Yellow
Switching Frequency
1000 Hz
1000 Hz
1000 Hz
1000 Hz
Start Up Delay
< 50 ms
< 50 ms
< 50 ms
< 50 ms
Repeability
< 3%
< 3%
< 3%
< 3%
Short Circuit Protection
Present (self-resetting)
Present (self-resetting)
Present (self-resetting)
Present (self-resetting)
Electric Protection
Against polarity reversal
inductive loads
Against polarity reversal
inductive loads
Against polarity reversal
inductive loads
Against polarity reversal
inductive loads
Temperature Limit
(-25 ... +70 °C)
(-25 ... +70 °C)
(-25 ... +70 °C)
(-25 ... +70 °C)
Protection Degree
IP67
IP67
IP67
IP67
Cable Length
---
2 m
---
2 m
Cable Section
---
2/3/4 x 0,25 mm²
---
2/3/4 x 0,25 mm²
Housing Material
Nickel-plated brass
Nickel-plated brass
Nickel-plated brass
Nickel-plated brass
Weight - Cable Output
---
110 g
---
110 g
Weight - M12 Connector Output
60 g
---
60 g
---
basic m12
