24
STANDARD
FLUSH
NON FLUSH
M12 conn
cable
M12 conn
cable
NOMINAL SWITCHING DISTANCE
5 mm
5 mm
8 mm
8 mm
10-30 Vdc
PNP/NPN
NO-NC
4 wires
IS-18-A0-S2
IS-18-A0-03
IS-18-C0-S2
IS-18-C0-03
order No.
95B064260
95B064230
95B064280
95B064240
10-30 Vdc
PNP
NO
3 wires
IS-18-A1-S2
IS-18-A1-03
IS-18-C1-S2
IS-18-C1-03
order No.
95B061351
95B061341
95B061751
95B061741
10-30 Vdc
PNP
NC
3 wires
IS-18-A2-S2
IS-18-A2-03
IS-18-C2-S2
IS-18-C2-03
order No.
95B061371
95B061361
95B061771
95B061761
10-30 Vdc
NPN
NO
3 wires
IS-18-A3-S2
IS-18-A3-03
IS-18-C3-S2
IS-18-C3-03
order No.
95B061311
95B061301
95B061711
95B061701
10-30 Vdc
NPN
NC
3 wires
IS-18-A4-S2
IS-18-A4-03
IS-18-C4-S2
IS-18-C4-03
order No.
95B061331
95B061321
95B061731
95B061721
10-30 Vdc
PNP
NO-NC
3 wires
---
---
---
---
order No.
---
---
---
---
10-30 Vdc
NPN
NO-NC
3 wires
---
---
---
---
order No.
---
---
---
---
10-30 Vdc
NO-NC
2 wires
IS-18-A9-S2
S-18-A9-03
IS-18-C9-S2
IS-18-C9-03
order No.
95B063941
95B064300
95B064340
95B064310
20-250 Vac/Vdc NO
2 wires
---
---
---
---
order No.
---
---
---
---
20-250 Vac/Vdc NC
2 wires
---
---
---
---
order No.
---
---
---
---
20-250 Vac/Vdc NO
2/3 wires
---
---
---
---
order No.
---
---
---
---
Analog 0-20mA -
3 wires
---
---
---
---
order No.
---
---
---
---
5+24 Vdc
NAMUR 2 wires
---
---
---
---
order No.
---
---
---
---
Nominal Voltage
10-30 Vdc (-15/10%)
10-30 Vdc (-15/10%)
10-30 Vdc (-15/10%)
10-30 Vdc (-15/10%)
Residual Ripple
< 10%
< 10%
< 10%
< 10%
Hysteresis
< 10%
< 10%
< 10%
< 10%
Max. Output Current
200 mA
200 mA
200 mA
200 mA
Min. Output Current
> 1,6 mA (2wires ver.)
> 1,6 mA (2wires ver.)
> 1,6 mA (2wires ver.)
> 1,6 mA (2wires ver.)
Residual Current
< 10 mA
< 10 mA
< 10 mA
< 10 mA
Voltage Drop
< 1,8V; < 6,5 V (2wires ver.)
< 1,8V; < 6,5 V (2wires ver.)
< 1,8V; < 6,5 V (2wires ver.)
< 1,8V; < 6,5 V (2wires ver.)
Operation Led
Yellow
Yellow
Yellow
Yellow
Switching Frequency
1000 Hz
1000 Hz
1000 Hz
1000 Hz
Start Up Delay
< 50 ms
< 50 ms
< 50 ms
< 50 ms
Repeability
< 3%
< 3%
< 3%
< 3%
Short Circuit Protection
Present (self-resetting)
Present (self-resetting)
Present (self-resetting)
Present (self-resetting)
Electric Protection
Against polarity reversal
inductive loads
Against polarity reversal
inductive loads
Against polarity reversal
inductive loads
Against polarity reversal
inductive loads
Temperature Limit
(-25 ... +60 °C)
(-25 ... +60 °C)
(-25 ... +60 °C)
(-25 ... +60 °C)
Protection Degree
IP67
IP67
IP67
IP67
Cable Length
---
2 m
---
2 m
Cable Section
---
2/3/4 x 0,25 mm²
---
2/3/4 x 0,25 mm²
Housing Material
Nickel-plated brass
Nickel-plated brass
Nickel-plated brass
Nickel-plated brass
Weight - Cable Output
---
145g
---
145g
Weight - M12 Connector Output
95g
---
95g
---
basic m18
