34
STANDARD
FLUSH
cable
NOMINAL SWITCHING DISTANCE
0,8 mm
10-30 Vdc
PNP/NPN
NO-NC
4 wires
---
order No.
---
10-30 Vdc
PNP
NO
3 wires
IS-04-A1-03
order No.
95B061011
10-30 Vdc
PNP
NC
3 wires
---
order No.
---
10-30 Vdc
NPN
NO
3 wires
IS-04-A3-03
order No.
95B061001
10-30 Vdc
NPN
NC
3 wires
---
order No.
---
10-30 Vdc
PNP
NO-NC
3 wires
---
order No.
---
10-30 Vdc
NPN
NO-NC
3 wires
---
order No.
---
10-30 Vdc
NO-NC
2 wires
---
order No.
---
20-250 Vac/Vdc NO
2 wires
---
order No.
---
20-250 Vac/Vdc NC
2 wires
---
order No.
---
20-250 Vac/Vdc NO
2/3wires
---
order No.
---
Analog 0-20mA -
3 wires
---
order No.
---
5+24 Vdc
NAMUR 2 wires
---
order No.
---
Nominal Voltage
10-30 Vdc (-15/10%)
Residual Ripple
< 10%
Hysteresis
< 15%
Max. Output Current
100 mA
Min. Output Current
---
Residual Current
< 0,01 mA
Voltage Drop
< 1,5 V
Operation Led
Yellow
Switching Frequency
2000 Hz
Start Up Delay
---
Repeability
< 1%
Short Circuit Protection
Present (self-resetting)
Electric Protection
Against polarity reversal
inductive loads
Temperature Limit
(-25 ... +70 °C)
Protection Degree
IP67
Cable Length
2 m (PUR)
Cable Section
3x 0,15 mm²
Housing Material
Stainless-Steel
Weight - Cable Output
50 g
Weight - M12 Connector Output
---
STAINLESS STEEL m4
