SHORT STAINLESS STEEL
FLUSH
M8 conn
M12 conn
cable
NOMINAL SWITCHING DISTANCE
1,5 mm
1,5 mm
1,5 mm
10-30 Vdc
PNP/NPN
NO-NC
4 wires
---
---
---
order No.
---
---
---
10-30 Vdc
PNP
NO
3 wires
IS-08-M1-S1
IS-08-M1-S2
IS-08-M1-03
order No.
95B066870
95B066600
95B066380
10-30 Vdc
PNP
NC
3 wires
IS-08-M2-S1
IS-08-M2-S2
IS-08-M2-03
order No.
95B066900
95B066630
95B066600
10-30 Vdc
NPN
NO
3 wires
IS-08-M3-S1
IS-08-M3-S2
IS-08-M3-03
order No.
95B066820
95B066540
95B066340
10-30 Vdc
NPN
NC
3 wires
IS-08-M4-S1
IS-08-M4-S2
IS-08-M4-03
order No.
95B066840
95B066570
95B066360
10-30 Vdc
PNP
NO-NC
3 wires
---
---
---
order No.
---
---
---
10-30 Vdc
NPN
NO-NC
3 wires
---
---
---
order No.
---
---
---
10-30 Vdc
NO-NC
2 wires
---
---
---
order No.
---
---
---
20-250 Vac/Vdc NO
2 wires
---
---
---
order No.
---
---
---
20-250 Vac/Vdc NC
2 wires
---
---
---
order No.
---
---
---
20-250 Vac/Vdc NO
2/3wires
---
---
---
order No.
---
---
---
Analog 0-20mA -
3 wires
---
---
---
order No.
---
---
---
5+24 Vdc
NAMUR 2 wires
---
---
---
order No.
---
---
---
Nominal Voltage
10-30 Vdc (-15/10%)
10-30 Vdc (-15/10%)
10-30 Vdc (-15/10%)
Residual Ripple
< 10%
< 10%
< 10%
Hysteresis
< 10%
< 10%
< 10%
Max. Output Current
200 mA
200 mA
200 mA
Min. Output Current
---
---
---
Residual Current
< 10 mA
< 10 mA
< 10 mA
Voltage Drop
< 1,2 V (I=100mA)
< 1,2 V (I=100mA)
< 1,2 V (I=100mA)
Operation Led
Yellow
Yellow
Yellow
Switching Frequency
1000 Hz
1000 Hz
1000 Hz
Start Up Delay
< 50 ms
< 50 ms
< 50 ms
Repeability
< 3%
< 3%
< 3%
Short Circuit Protection
Present (self-resetting)
Present (self-resetting)
Present (self-resetting)
Electric Protection
Against polarity reversal
inductive loads
Against polarity reversal
inductive loads
Against polarity reversal
inductive loads
Temperature Limit
(-25 ... +70 °C)
(-25 ... +70 °C)
(-25 ... +70 °C)
Protection Degree
IP67
IP67
IP67
Cable Length
---
---
---
Cable Section
---
---
3x 0,14 mm²
Housing Material
Stainless-Steel
Stainless-Steel
Stainless-Steel
Weight - Cable Output
---
---
80 g
Weight - M12 Connector Output
35g
55g
---
STAINLESS STEEL m8
