10
STANDARD
FLUSH
NON FLUSH
M8 conn
cable
M8 conn
cable
NOMINAL SWITCHING DISTANCE
1,5 mm
1,5 mm
2 mm
2 mm
10-30 Vdc
PNP/NPN
NO-NC
4 wires
---
---
---
---
order No.
---
---
---
---
10-30 Vdc
PNP
NO
3 wires
IS-65-A1-S1
IS-65-A1-03
IS-65-C1-S1
IS-65-C1-03
order No.
95B066050
95B064730
95B066210
95B064890
10-30 Vdc
PNP
NC
3 wires
IS-65-A2-S1
IS-65-A2-03
IS-65-C2-S1
IS-65-C2-03
order No.
95B066090
95B064770
95B066250
95B066300
10-30 Vdc
NPN
NO
3 wires
IS-65-A3-S1
IS-65-A3-03
IS-65-C3-S1
IS-65-C3-03
order No.
95B064970
95B064650
95B066130
95B064810
10-30 Vdc
NPN
NC
3 wires
IS-65-A4-S1
IS-65-A4-03
IS-65-C4-S1
IS-65-C4-03
order No.
95B066010
95B064690
95B066170
95B064850
10-30 Vdc
PNP
NO-NC
3 wires
---
---
---
---
order No.
---
---
---
---
10-30 Vdc
NPN
NO-NC
3 wires
---
---
---
---
order No.
---
---
---
---
10-30 Vdc
NO-NC
2 wires
---
---
---
---
order No.
---
---
---
---
20-250 Vac/Vdc NO
2 wires
---
---
---
---
order No.
---
---
---
---
20-250 Vac/Vdc NC
2 wires
---
---
---
---
order No.
---
---
---
---
20-250 Vac/Vdc NO
2/3wires
---
---
---
---
order No.
---
---
---
---
Analog 0-20 mA -
3 wires
---
---
---
---
order No.
---
---
---
---
5+24 Vdc
NAMUR 2 wires
---
---
---
---
order No.
---
---
---
---
Nominal Voltage
10-30 Vdc (-15/10%)
10-30 Vdc (-15/10%)
10-30 Vdc (-15/10%)
10-30 Vdc (-15/10%)
Residual Ripple
< 10%
< 10%
< 10%
< 10%
Hysteresis
< 10%
< 10%
< 10%
< 10%
Max. Output Current
200 mm
200 mA
200 mm
200 mA
Min. Output Current
---
---
---
---
Residual Current
< 1,6 mA
< 1,6 mA
< 1,6 mA
< 1,6 mA
Voltage Drop
< 1,2 V (I=100 mA)
< 1,2 V (I=100 mA)
< 1,2 V (I=100 mA)
< 1,2 V (I=100 mA)
Operation Led
Yellow
Yellow
Yellow
Yellow
Switching Frequency
1000 Hz
1000 Hz
1000 Hz
1000 Hz
Start Up Delay
< 50 ms
< 50 ms
< 50 ms
< 50 ms
Repeability
< 3%
< 3%
< 3%
< 3%
Short Circuit Protection
Present (self-resetting)
Present (self-resetting)
Present (self-resetting)
Present (self-resetting)
Electric Protection
Against polarity reversal
inductive loads
Against polarity reversal
inductive loads
Against polarity reversal
inductive loads
Against polarity reversal
inductive loads
Temperature Limit
(-25 ... +70 °C)
(-25 ... +70 °C)
(-25 ... +70 °C)
(-25 ... +70 °C)
Protection Degree
IP67
IP67
IP67
IP67
Cable Length
---
2 m
---
2 m
Cable Section
---
3x 0,14 mm²
---
3x 0,14 mm²
Housing Material
Nickel-plated brass
Nickel-plated brass
Nickel-plated brass
Nickel-plated brass
Weight - Cable Output
---
80 g
---
80 g
Weight - M12 Connector Output
40 g
---
40 g
---
basic m6.5
