RG-InductiveSensors2013-EN - page 7

7
METAL FACE 46
• Stainless Steel housing
• Stainless Steel active face
• Standard length
• 2 … 8 mm
• M12, M18
• M12 connector
• 3 wires
• PNP, NO
• IP67 protection
WELD FIELD IMMUNE 50
• Stainless Steel housing
• PTFE active face
• Standard length
• Operating distance 2 … 8 mm
• M12, M18
• M12 connector
• 3 wires
• PNP, NO
• IP67 protection
SQUARE 70
• PBT (resin) or Nickel-plated Brass housing
• Operating distance 1.5 … 15 mm
• 40x40 mm or 8x8 mm dimension
• cable, M8 connector or Terminal Block
• 2 or 3 wires
• PNP, PNP/NPN, NO, NC, NO/NC
• IP67
CABLES, CONNECTORS & ACCESSORIES 76
• 2,3,4 wires
• M12, M8 connector
• axial or radial 90°
• shielded or unshielded
• double key
• A.C. cable
• 3, 5, 7, 10, 15, 25m cable
--flush, non-flush
--Stainless Steel, Nickel plated-
Brass
--op.dist.: 5…8 mm
--double range vers.: 8…14 mm
--diameter: 18 mm
--standard or short housing
--2, 3 4 (programmable NPN/PNP
output) wires
--Vac/Vdc vers.
--Metal Face vers.
--Field Immune vers.
--NAMUR vers.
--PNP or NPN, N.O., N.C.
--M12 connector or cable
--flush, non-flush
--Stainless Steel, Nickel plated-
Brass
--op.dist.: 10…15 mm
--double range vers.: 15…20 mm
--diameter: 30 mm
--standard or short housing
--2, 3, 4 (programmable NPN/
PNP output) wires
--Vac/Vdc vers.
--NAMUR vers.
--PNP or NPN, N.O., N.C.
--M12 connector or cable
--flush, non-flush
--standard or short housing
--Plastic (PBT resin)
--op.dist.: 15…30 mm; 7-20 mm
(Analog vers.)
--diameter: 40 mm
--2, 3 wires
--Vac/Vdc vers.
--Analog output 4-20mA vers.
--PNP or NPN, N.O., N.C.
--Terminal block
--flush
--Nickel-Plated Brass
--op.dist.: 1,5 mm
--diameter: 8 mm
--3 wires, PNP, N.O.
--M8 connector or cable
M18 M30 SQUARE 40X40 SQUARE 8X8
CABLES,CONNECTORS& ACCESSORIES
SQUARE
NAMUR INDUCTIVE AC WELD FIELD
IMMUNE
METALFACE
STAINLESSSTEEL
BASIC
pag
32
pag
08
pag
46
pag
50
pag
54
pag
60
pag
70
pag
76
