67
NAMUR
FLUSH
NON FLUSH
M12 conn
cable
M12 conn
cable
NOMINAL SWITCHING DISTANCE
5mm
5mm
8mm
8mm
10-30 Vdc
PNP/NPN
NO-NC
4 wires
---
---
---
---
order No.
---
---
---
---
10-30 Vdc
PNP
NO
3 wires
---
---
---
---
order No.
---
---
---
---
10-30 Vdc
PNP
NC
3 wires
---
---
---
---
order No.
---
---
---
---
10-30 Vdc
NPN
NO
3 wires
---
---
---
---
order No.
---
---
---
---
10-30 Vdc
NPN
NC
3 wires
---
---
---
---
order No.
---
---
---
---
10-30 Vdc
PNP
NO-NC
3 wires
---
---
---
---
order No.
---
---
---
---
10-30 Vdc
NPN
NO-NC
3 wires
---
---
---
---
order No.
---
---
---
---
10-30 Vdc
NO-NC
2 wires
---
---
---
---
order No.
---
---
---
---
20-250 Vac/Vdc NO
2 wires
---
---
---
---
order No.
---
---
---
---
20-250 Vac/Vdc NC
2 wires
---
---
---
---
order No.
---
---
---
---
20-250 Vac/Vdc NO
2/3wires
---
---
---
---
order No.
---
---
---
---
Analog 0-20mA -
3 wires
---
---
---
---
order No.
---
---
---
---
5+24 Vdc
NAMUR 2 wires
IS-18-A20-S2
IS-18-A20-03
IS-18-C20-S2
IS-18-C20-03
order No.
95B064380
95B064360
95B064390
95B064370
Nominal Voltage
7,7 + 9 V DC
7,7 + 9 V DC
7,7 + 9 V DC
7,7 + 9 V DC
Residual Ripple
< 10%
< 10%
< 10%
< 10%
Hysteresis
< 10%
< 10%
< 10%
< 10%
Max. Output Current
< 3 mA (metal absent)
< 3 mA (metal absent)
< 3 mA (metal absent)
< 3 mA (metal absent)
Min. Output Current
< 1 mA (metal present)
< 1 mA (metal present)
< 1 mA (metal present)
< 1 mA (metal present)
Residual Current
---
---
---
---
Voltage Drop
---
---
---
---
Operation Led
Yellow
Yellow
Yellow
Yellow
Switching Frequency
1000 Hz
1000 Hz
1000 Hz
1000 Hz
Start Up Delay
---
---
---
---
Repeability
< 3%
< 3%
< 3%
< 3%
Short Circuit Protection
Present (self-resetting)
Present (self-resetting)
Present (self-resetting)
Present (self-resetting)
Electric Protection
Against polarity reversal
inductive loads
Against polarity reversal
inductive loads
Against polarity reversal
inductive loads
Against polarity reversal
inductive loads
Temperature Limit
(-25 ... +60 °C)
(-25 ... +60 °C)
(-25 ... +60 °C)
(-25 ... +60 °C)
Protection Degree
IP67
IP67
IP67
IP67
Cable Length
---
2 m
---
2 m
Cable Section
---
2 x 0,25 mm²
---
2 x 0,25 mm²
Housing Material
Stainless-Steel
Stainless-Steel
Stainless-Steel
Stainless-Steel
Weight - Cable Output
---
145g
---
145g
Weight - M12 Connector Output
95g
---
95g
---
NAMUR
NAMUR M18
