72
40x40
FLUSH
NON FLUSH
Terminal Block
Terminal Block
NOMINAL SWITCHING DISTANCE
15 mm
30mm
10-30 Vdc
PNP/NPN
NO-NC
4 wires
---
---
order No.
---
---
10-30 Vdc
PNP
NO
3 wires
---
---
order No.
---
---
10-30 Vdc
PNP
NC
3 wires
---
---
order No.
---
---
10-30 Vdc
NPN
NO
3 wires
---
---
order No.
---
---
10-30 Vdc
NPN
NC
3 wires
---
---
order No.
---
---
10-30 Vdc
PNP
NO-NC
3 wires
IS-40-W5-S3
IS-40-Y5-S3
order No.
95B065240
95B065280
10-30 Vdc
NPN
NO-NC
3 wires
IS-40-W6-S3
IS-40-Y6-S3
order No.
95B065230
95B065270
10-30 Vdc
NO-NC
2 wires
---
---
order No.
---
---
20-250 Vac/Vdc NO
2 wires
---
---
order No.
---
---
20-250 Vac/Vdc NC
2 wires
---
---
order No.
---
---
20-250 Vac/Vdc NO
2/3wires
---
---
order No.
---
---
Analog 0-20mA -
3 wires
---
---
order No.
---
---
5+24 Vdc
NAMUR 2 wires
---
---
order No.
---
---
Nominal Voltage
10-30 Vdc
10-30 Vdc
Residual Ripple
< 10%
< 10%
Hysteresis
< 15% (Sr)
< 15% (Sr)
Max. Output Current
200mA
200mA
Min. Output Current
---
---
Residual Current
< 0,01 mA
< 0,01 mA
Voltage Drop
< 1,5V
< 1,5V
Operation Led
YES
YES
Switching Frequency
100 Hz
100 Hz
Start Up Delay
---
---
Repeability
< 1.0% (Sr)
< 1.0% (Sr)
Short Circuit Protection
Present (self-resetting)
Present (self-resetting)
Electric Protection
Against polarity reversal
inductive loads
Against polarity reversal
inductive loads
Temperature Limit
(-25 ...+75C)
(-25 ... +75 °C)
Protection Degree
IP67
IP67
Cable Length
---
---
Cable Section
---
---
Housing Material
PBT ( RESIN)
PBT ( RESIN)
Weight - Cable Output
---
---
Weight - M12 Connector Output
262g
262g
SQUARE 40X40
