WIRING DIAGRAms
WIRING DIAGRAms
WIRING DIAGRAms
CONNECTOR
TYPE
ORIENTATION
LENGTH
MATERIAL
CODING
ORDER No.
M12
"shielded
AC sensors"
axial, double key
2m
PVC
CS-A1-21-R-03
95A252880
5m
CS-A1-21-R-05
95A252890
2-3 POLES - AC CABLES
WARNING: The load can be indifferently connected in series
to the blue wire or to the brown wire to simulate NPN or PNP
functionning logic.
Double key connector for inductive AC sensors
NO
BROWN
BLUE
NC
BROWN
1) SC protection see tech. data
NAMUR
SENSOR
BROWN
BLUE
BU
BK
GNYE
GNYE
BLUE
View of
quadripole
male connector
CONTACTS CONFIGURATION
Available
Contacts numbers
1
2
3
4
NAMUR
+
–
CONTACTS CONFIGURATION
Available
Contacts numbers
1
3
4
NAMUR
+
–
View of
triple male
connector
View of
quadripole
male connector
CONTACTS CONFIGURATION
Available
Contacts numbers
1
2
3
4
NO
+
–
NC
–
+
CONNECTION
WITH CONNECTOR M12
CONNECTION
WITH CONNECTOR M8
CONNECTION
WITH CONNECTOR M12
