ulyxe SERIES
Ulyxe lasers
, with 6W@1064nm, are
classified as DPSS Active Q-Switched
Lasers. This family is extremely
compact (only 42cm, 16.5”) but offers
all of the most advanced technological
concepts.
The Ulyxe family provides
the best price to performance ratio
in the laser marking world
. As a
result of its cost-effectiveness and
competitive positioning, the Ulyxe
family is the first choice in marking
solutions even when compared with
traditional marking techniques. With
its extreme compactness, this laser
family represents the ideal laser
marking solution both in standalone
configurations as well as OEM
applications.
The air cooled laser sources offer an
ultra-compact design and includes
the scanning head, digital control and
monitoring functions. The outside
cover on the units are equipped with
a specifically designed high-tech
case, available in different materials
(polyurethane and metal) depending on
different application requirements. The
operator can easily interact and monitor
important laser statuses and functions
with a user-friendly LCD touch screen
control display.
The Ulyxe compact laser family is
available in two different control
configurations (USB embedded
controller and IMARk control kit) and in
two case styles , bicolors thermoplastic
or stainless steel case.
Applications
•Plastic and metal marking in automotive,
electronics and healthcare industries
•Label Marking
•DPM (Direct Part Marking)
•Tool Marking
•Marking on surgical tools/d
evices
technical dAta
USB EMBEDDED CONTROLLER
IMARK CONTROL KIT
Wavelenght
1064nm
Nominal power
6W
Repetition Rate range
15-200 kHz
Pulse Width
20-25 ns@20kHz
Max Pulse Energy
300µJ@15 kHz
Aiming Beam
Red Laser Diode 635 nm
Focus Beam
Red Laser Diode 635 nm
Connectivity
USB
PCIe slot
Power Supply
24VDC/13A
Cooling System
Air cooled
Temperature Range
Operative 15°C to 35°C
-5 to +55 °C
Dimensions
426x154x170 mm
410x145x123 mm
IMARK CONTROL KIT
Ulyxe now supports iMark PCIe control
platform controller, enabling advanced
Lighter features and up to 4 axis controls
(X,Y,Z and rotative axis) to implement
multi-layers and rotating marking. Ulyxe
with iMark is available only with metal
cover
USB EMBEDDED
CONTROLLER
With an embedded DPS controller, the
Ulyxe combines compact dimensions
with user-friendly interface (LIGHTER
Suite) installation and set-up.
Laser marking has never been easier.
This configuration is available for both
polycarbonate or metal cases.
