arex SERIES
AREX series
represents the ultimate Fiber Laser marking system in
unmatched compactness.
AREX is the
ultra-compact pulsed fiber laser system
ideal for Direct
Part Marking in the automotive and electronics industry as well as
label marking on metal parts, plastic parts and components.
Available in
10W, 20W, 30W and 50W
fiber laser sources, improved
scan head, compact controller rack design and advanced LIGHTER
Software features, the AREX increases performance in term of
power, reliability, quick installation and setup, flexible programming
and control. Higher output power increases marking performance
in term of speed marking and deep engraving. With
IP54 protection
class scan head and 50°C (120°F) operating temperature*
, AREX
series guarantees higher reliability even in harsh environments.
AREX drastically simplifies system design and machine integration
,
all you need for your marking application is inside and included.
Laser marker setup and operation are made easy
with the
Embedded Marker Controller platform (EMC) and LIGHTER Suite.
Embedded Red Laser Spot for focus position allows fast focusing of
the laser beam during setup.
With the user friendly HMI, the operator can define any kind of
label, logo, text, datamatrix, and bar codes for laser labeling and
traceability applications.
AREX is equipped with
4 independent axis
controls (X,Y,Z, Rotating
axis) to implement multi-layers and rotating marking.
Dedicated encoder input is applied for
Marking On Fly (MOF)
even
in accelerated and variable speed conditions. Advanced software
functions support a variety of conditions including operator
attended working station and fully automated marking centers.
Applications
•Plastic and metal marking in automotive,
electronics and healthcare industries
•2D codes marking on automotive parts
•Laser Annealing on precision metal
components and medical equipment
•Deep engraving marking
technical dAta
AREX 10
AREX 20
AREX 30
AREX 50
Nominal power
10W
20W
30W
50 W
Pulse energy (max)
0.5mJ
1,0mJ
1,0 mJ
1,0mJ
Peak power (max)
5 kW
10 kW
10 kW
10 kW
Modulation
20 kHz ÷ 100 kHz
30 kHz ÷ 100 kHz
20 kHz ÷ 100 kHz
Laser source
Pulsed Fiber Laser
Pulsewidth (Typ)
100 ns
Aiming & Focus Beam
Red Laser Diode 635 nm
Protection degree
Head: IP54 Controller: IP 21
Cooling
Air cooled
Power Supply
100/240 VAC – 50/60 Hz – 400 W (MAX)
Resonator Dimension
90x112x298 mm3
Rack Dimension
106x430x370 mm3
*Only on AREX10 and AREX20
