eox SERIES
EOX
is the
CO2 Laser family for laser coding and marking
applications. The EOX family offers high quality permanent
marking on a wide range of materials including cardboard,
ceramic, wood, plastics and painted or anodized metal. Combining
excellent laser beam quality and advanced control unit, the EOX
family is suitable for accurate industrial traceability as well as
high productivity coding applications.
CO2 laser family is available in 2 power levels,
10W and 30W
,
with the same marking platform but with different mechanical
configurations. 10W versions are offered in an
ALL-IN-ONE
case
with very compact dimensions. 30W versions combine of a
compact marking head
with a control rack equipped with power
supply and control unit.
Both 10W and 30W versions provide
axis control and an encoder
port for Marking On the Fly (MOF
), which is typically required for
coding applications. Advanced MOF features offers complete
synchronization between marking head and object movement
even in accelerated or start-s top movement conditions.
MOF
increases production lines throughput with linear speeds up to
75mt/min and 12.000 pcs/hour
. A CO2 marking system is very
attractive for low cost of operation coding applications, due to no
maintenance and no requirement for expensive consumables.
The EOX meets flexibility requirements with extended marking
area up to 140x140mm (focal lens dependent). Reliable and safe,
the EOX family provides a clean technology with short return of
investment and minimal maintenance.
technical dAta
EOX 10
EOX 30
Wavelenght
10,6 µm
10,6 µm
Nominal power
10W
30W
Repetition Rate Range
10-25000 Hz
Aiming Beam
Class Red Laser Diode 635 nm
Focus Beam
Class Red Laser Diode 635 nm
Power Supply
100/240 VAC - 50/60 Hz
Cooling System
Air cooled
Temperature Range
Operative 15°C to 35°C
-10 to +60 °C
Head dimensions
180x185x634 mm
180x185x634 mm
Rack dimensions
-
437x94x333 mm
Applications
•Coding and marking applications in food, pharmaceutical,
and electronics industries
