AV 시리즈

AV 시리즈

The AV series of readers are high-performance industrial imagers for either attended or unattended data capture solutions



알아보기 & 체험하기

The AV500 reader creates a new optical standard for unattended data capture solutions with an industry-leading 5 megapixel resolution CMOS sensor, image acquisition at 32 frames per second, dynamic focus or adjustable focus, and multiple lens options.

With a wide field-of-view and excellent depth-of-field provided by several dynamic focus options, the AV500 barcode reader is an ideal choice for smart track logistic solutions, baggage handling systems, and retail smart distribution applications.

Continuous frame acquisition, no-flashing white or red integrated illumination, and colored spot indicators make the AV500 reader the unprecedented solution for operator-attended applications such as manual object presentation in overhead scanning mode or manual conveyor loading.

The AV900 high-performance industrial imager is a highly capable and vastly superior camera for transport and logistics applications. It sets a high bar for 2D image-based readers on all conveyor sizes, airport baggage handling systems as well as static reading applications. In addition to its high-resolution capabilities, users can choose from different optics and set up either dynamic or SW adjustable focus to tweak performance to suit your needs.

With a powerful 9 MP CMOS sensor, the AV900 provides users with 60% additional coverage compared to the widely used 5 MP cameras. Putting this into perspective for wide areas, users can achieve the same coverage from three AV900 cameras as five 5 MP cameras. Images are captured in HD quality and can be saved in multiple formats for video coding and OCR.

The AV900 is capable of continuously capturing very high-resolution images up to 32 frames per second. Datalogic’s patented PackTrack technology is instrumental in ensuring top performance even at reduced gaps between items, without any risk of mis-assignments. All your data will be captured, even with your conveyor loaded at maximum capacity.

다운로드 AV 시리즈

고객 지원

EASE OF CARE 서비스 프로그램

우리의 사명은 고객의 프로필과 산업 영역에서의 모든 상호 작용에 적합한 최상의 서비스를 제공하는 것입니다. 고객 중심의 서비스를 위해 주문 입력 및 확인 서비스 부터 A/S와 설치 서비스에 이르기까지 전 세계적으로 그룹이 제공하는 모든 서비스를 중앙 집중화된 고객 서비스 센터를 통해 제공하고 있으며, 포춘지 선정 글로벌 500대 기업이 체택하고 있는 NPS (Net Promote Score)와 같은 고객 만족도 설문 조사의 지표를 반영하여 서비스 품질을 관리하고 있습니다. 데이터로직의 고객 서비스 센터는 고객의 요청 사항에 간결하고 일관된 대응 경로를 보장할 것입니다. 권한과 능력을 갖춘 전문 인력들은 고객과 함께 소통하며, 각 각의 사안이 모두 완료될 때까지 전담하여 처리할 것입니다. 데이터로직의 고객 서비스 조직은 광범위하고 완벽한 판매 후 서비스 EOC(EASE OF CARE)를 제공하며, 이는 특정 문제에 따라 최적화된 전문적 지원을 보장하기 위해, 지원 수준은 3단계로 구성되어 있습니다. 데이터로직의 고객 서비스 센터는 전체 제품 범위에 걸쳐 광범위한 전문적 기술 지식을 갖춘 다국어 전문가 팀을 해당 지역에 배치할 수 있습니다.

데이터로직 표준 서비스 포트폴리오:

미디어

모델 & 액세서리

AV500-166R, 16mm, f/6, RED
938000017
AV500-166W, 16mm, f/6, WHITE
938000007
AV500-257R, 25mm, f/7, RED
938000015
AV500-257W, 25mm, f/7, WHITE
938000005
AV500-258R, 25mm, f/8, RED
938000016
AV500-258W, 25mm, f/8, WHITE
938000006
AV500-357R, 35mm, f/7, RED
938000011
AV500-357W, 35mm, f/7, WHITE
938000001
AV500-358R, 35mm, f/8, RED
938000012
AV500-358W, 35mm, f/8, WHITE
938000002
AV900-257R, 25mm, f/7, RED
938000115
AV900-257W, 25mm, f/7, WHITE
938000105
AV900-358R, 35mm, f/8, RED
938000112
AV900-358W, 35mm, f/8, WHITE
938000102
AV500, EOC Overnight Comp, 1 Year Rnw
ZSC1AV500R1
AV500, EOC, 5 Days, 1 Year Rnw
ZSN5AV500R1
AV500, EOC, 5 Days, 3 Years
ZSN5AV50031
AV500, EOC, 5 Days, 5 Years
ZSN5AV50051
AV500, EOC, Overnight, Comp, 3 Years
ZSC1AV50031
AV500, EOC, Overnight, Comp, 5 Years
ZSC1AV50051
CAB-GE01 M12-IP67 TO RJ45 1M
93A050034
CAB-GE03 M12-IP67 TO RJ45 3M
93A050035
CAB-GE03 M12M TO M12F 3M
93A050079
CAB-GE05 M12-IP67 TO RJ45 5M
93A050036
CAB-GE05 M12M TO M12F 5M
93A050080
CAB-GE10 M12-IP67 TO RJ45 10M
93A051389
CAB-GE10 M12M TO M12F 10M
93A050081
CBL AV7-100 M16-IP67 CABLE TO CBX 3M
93A050072
CBL-AV7-101 M16-IP67 CABLE TO CBX 5M
93A050073
CBL-AV7-102 M16-IP67 CABLE TO CBX 10M
93A050074
CS-A1-02-G-05 = M12 4-p axial 5m
95A251270
CS-A1-02-G-10 = M12 4-p axial 10m
95A251390
CS-A1-03-G-03 = M12 5-p axial 3m
95ACC2110
CS-A1-03-G-05 = M12 5-p axial 5m
95ACC2120
CS-A1-03-G-10 = M12 5-p axial 10m
95ACC2140
Focus Control 5mt cable (M12-free wires).
93A201203
AS1-HD-SR-010-J D 3m RES 5mm H 100mm
958101030
CBX100 CONNECTION BOX COMPACT
93A301067
CBX500 CONNECTION BOX MODULAR
93A301068
CBX510 CONNECTION BOX, DS8110/DX8210
93A301087
CBX800 GATEWAY
93A301077
DK-503 DISTANCE KIT RS485 + CABLE 5m
93ACC0263
DMS100-100 DIM SOLU 1HD STD NLFT
932702110
DUAL GIG 8-PORT SWITCH ENCLOSURE
93ACC0131
KIT,S62 PNP PHOTOCELL,R3 REFL/BRKT/HDWR
93ACC1895
LCC-7501 AV7 LIGHT CURTAIN 150MM+CAB 10M
93ACC0170
LCC-7506 AV7 LIGHT CURTAIN 600MM+CAB 10M
93ACC0171
LCC-7509 AV7 LIGHT CURTAIN 900MM+CAB 10M
93ACC0172
LCC-7512 AV7 LIGHT CURTAIN 1200MM+CAB 10
93ACC0173
MEP-593 PHOTOCELL KIT
93ACC1791
MULTIPORT (4PORT) PWR JUNCTION BOX
93ACC0121
MULTIPORT (8PORT) PWR JUNCTION BOX
93ACC0147
SINGLE GIG 8-PORT SWITCH ENCLOSURE
93ACC0160
AV-SP WS+ INVESTIGATOR, 1YR
93A100035
AV-SP WS+ INVESTIGATOR, 3YRS
93A100036
AV-SP WS+ INVESTIGATOR, RENEW 1YR
93A100037
AV-SP WS+ INVESTIGATOR, RENEW 3YRS
93A100038
