MX-SERIES Gig-E CAMERAS
GRAY-SCALE MODEL COLOR MODEL SHUTTER RESOLUTION IMAGER FRAME RATE (FPS) DIMENSIONS
M100 M100C Global 640 x 480 1/4” CCD 100
29 x 29 x 60.3 mm
(1.14 x 1.14 x 2.37 in
M110 M110C Global 640 x 480 1/3” CCD 90
M115 M115C Global 659 x 494 1/2" CCD 100
M125 M125C Global 782 x 582 1/2" CCD 75
M150 M150C Global 1296 x 966 1/3” CCD 30
M180 M180C Global 1628 x 1236 1/1.8” CCD 20
M190 M190C Global 2048 x 1088 2/3” CMOS 50
M195 M195C Global 2048 x 2048 1” CMOS 25
M197 M197C Rolling 2592 x 1944 1/2.5” CMOS 14
M200 M200C Global 659 x 494 1/3” CCD 70
44 x 29 x 85.5 mm
(1.73 x 1.14 x 3.37 in)
M202 M202C Global 659 x 494 1/2” CCD 79
M205 M205C Global 752 x 480 1/3” CMOS 64
M210 M210C Global 782 x 582 1/2” CCD 55
M230 M230C Global 1034 x 779 1/3” CCD 31
M250 M250C Global 1280 x 960 1/3” CCD 32
M270 M270C Global 1392 x 1040 2/3” CCD 30
M290 M290C Global 1628 x 1236 1/1.8” CCD 14
M295 M295C Global 1628 x 1236 1/1.8” CCD 28
M300 M300C Global 648 x 488 1/3” CCD 210
44 x 29 x 98.5 mm
(1.73 x 1.14 x 3.88 in
M330 M330C Global 1004 x 1004 2/3” CCD 60
M350 M350C Global 1608 x 1208 1” CCD 35
M390 M390C Global 2448 x 2050 2/3” CCD 17
digital cameras
MX-SERIES CAMERAS
MX-Series cameras enable fast integration of challenging
machine vision solutions. The unique ability to mix and
match color, gray-scale and line scan cameras with an
MX-Series processor lets the user define, select and deploy
a solution for high-speed, multi-camera machine vision
inspections.
MX-SERIES LINE-SCAN Gig-E CAMERAS
MODEL RESOLUTION MAX. LINE RATE PIXEL SIZE C-MOUNT F-MOUNT
M565 2048 48 KHz 7x7 μm • •
M570 4096 24 KHz 7x7 μm •
