29
SMART CAMERAS
A30
T4x
FORMAT
Right angle
Right angle
IMAGER
• 640 x 480, 1/3” CCD, 60 fps
• 640 x 480, 1/3” CCD, 60 fps
• 1600 x 1200, 1/1.8” CCD, 15 fps
• 2448 x 2048, 2/3” CCD, 15 fps
8-bit gray-scale
8-bit gray-scale
LENS MOUNT
C-Mount
C-Mount
PROCESSOR
800 MHz
DaVinci
1.1 GHz
DaVinci
ON-BOARD
IMAGE BUFFERING
Up to 16
Up to 16
ON-BOARD
PROGRAM STORAGE
256 MB flash
256 MB flash
DEDICATED ON-BOARD
OPTICALLY ISOLATED I/O
1 IN / 1 OUT
1 IN / 1 OUT
CONFIGURABLE
ON-BOARD OPTICALLY ISOLATED I/O
1 IN / 2 OUT
1 IN / 2 OUT
RS-232 SERIAL
•
•
ETHERNET
•
•
EXTERNAL BUTTON
•
•
POWER REQUIRED
10 … 30 VDC
1 … 0.33 A
• T40
10 … 30 VDC
1 … 0.33 A
• T47
10 … 30 VDC
1.05 … 0.35 A
•T49
10 … 30 VDC
1.2 … 0.4 A
DIMENSIONS
123 x 60 x 86 mm
(4.84 x 2.36 x 3.41 in)
123 x 60 x 101 mm
(4.84 x 2.36 x 3.98 in)
MECHANICAL PROTECTION
IP67
IP67
OPERATING TEMPERATURE
0 °C … +45 °C
0 °C … +50 °C
HUMIDITY
(NON-CONDENSING)
0 … 90 %
0 … 90 %
CERTIFICATIONS
CE, CSA
CE, CSA
