CODE READERS & OCR
MEASUREMENT
DATA COMMUNICATION
LOGIC PROGRAMMING IMAGE CALIBRATION
• Pixel or subpixel accuracies are possible
• Measure the angle between to linear objects
• Make multiple measurements within one tool
• Point to point and pont to line measurements
• Measure radius, center, and concentricity of circular objects
• State of the art 1D and 2D barcode readers. Find multiple codes within
one image
• Extremely wide range of code symbologies supported
• Omni-directional code reading
• OCR – Optical Character Recognition – able to read character strings
• OCV – Optical Character Verification – able to verify if the content of a
string matches with a trained one
• Discrete I/O, serial, TCP/IP and Ethernet/
IP available
• Supports HTTP, FTP and web serving
protocols
• ActiveX controls available for 3rd party
Microsoft® applications
• Modbus, PCCC and OPC server
communication
• Tree-view programming structure allows
for better tool organization and only run
tools when requested
• Logic tools allow for decision-making
capabilities without scripting
• Perform logical and mathematical
calculations in a flexible and easy way
• Allows a user to remove perspective and
radial distortion from an image as well as
convert pixel to real world values
• Unwrap a curved object or correct a slanted
object within an image (primarily used with
OCR)
• Combine multiple images into one large
• Reduce resolution by sampling the image
