CONTROL PANEL MANAGER (CPM)
Control Panel Manager
(CPM) simplifies
development of operator
interfaces while providing
the ability to make on-
the-fly adjustments to
critical machine controls.
Use CPM to create
operator interface panels
to view and adjust critical
machine controls.
•
Easy to understand
, tree-view logic flow
• Tool Setups guide users through
step-by-step
tool
configuration
• Includes
inspection and user interface development programs
as well as a
runtime user interface
• Runs on
all smart camera
and
vision p
r
ocessor platforms
• Provides
complete programmatic
or
manual control of hardware settings
• Provides
real time parameter changes of cameras
•
Controls and displays images and data
from multiple smart cameras or
vision processors
•
Password protection
allows only authorized users to make changes
•
Built-in Emulator
saves time when creating, testing and debugging your
vision program without a camera
• Software easily communicates with
higher level control system via TCP/IP,
Ethernet/IP, Modbus and OPC protocols.
HIGHLIGHTS
Impact Software powers the full line of integrated vision solutions,
from simple to complex. The investment in software and training is
preserved as inspections grow. Programs for the same inspections
can be easily shared or transferred across multiple inspection
points within the factory.
One software – countless applications!
CPM
