vsm
vision sensors
• 3.5’’ LCD color display and 8 push buttons
• 20 additional memory slots
• Image and result visualization
• Parameter fine tuning
• DIN rail or panel mounting
• 2 industrial M12 connectors
VSM is a monitoring device compatible with all DataVS2 vision sensor models. The device features a
3.5’’ LCD color display and 8 push buttons. It also embeds a standard TCP/IP Ethernet interface thus
it can be connected either directly to a specific vision sensor or to a LAN where more sensors have
been previously installed.
VSM allows to display images and results as well as to change the running inspection or also to
adjust the vision sensor functioning parameters.
Thanks to this wide range of functionalities, the device represents an excellent and complete HMI
interface ideal for automated production lines attended by operators.
datavs2
• Flexible and intuitive setup via PC through Ethernet
• Memorization of 20 inspections
• 14 different controls
• Logical operators: AND, OR, NOT, NAND, NOR, etc.
• TURBO mode to double elaboration speed
• VSM compatibility
The DATAVS2 vision sensor series presents all the characteristics able to solve artificial machine
vision applications in a flexible and intuitive way. DATAVS2 is a completely embedded device: the
optic, the LED illuminator and electronics are included in an extremely compact housing. The sensor
is configured via PC through Ethernet communication. The configuration software is included in the
product and it has been developed in order to lead the customer through the configuration process
step by step.
DATAVS2 is available in four different versions according to the installed control tools: Object
Recognition (OBJ), Advanced Object Recognition (AOR), Identification (ID) and Professional (PRO). Many
different control typologies are available: brightness, contrast, position, width, count, pattern match,
contour match, 360° pattern match, barcode and datamatrix reader, OCV, 360° contour match.
