CONNECTIVITY
CBX500
CBX800
QL500-QLM500/600/700
The CBX800 industrial connectivity device serves as a gateway, connecting devices equipped with a
standard RS232 communication interface to the most common fieldbus systems, through a complete
range of option module options, in addition to an ID-NET™ high speed communication network.
The Quick Link series, available in 5 different models, is a complete range of accessories for connectivity
dedicated to 1D and 2D bar code readers. Quick Link accessories offer an easy, fast, modular and cost-
effective solution for the applications where ”plug-in” connection is preferable.
FEATURES & BENEFITS
• Serial to Fieldbus / Ethernet TCP/IP/ID-NET™ industrial gateway
• Open architecture provides interface to Ethernet TCP/IP, PROFIBUS, DeviceNet Ethernet/IP and other
common networks
• Visible led indicators and power on/off switch
• Multilanguage Genius™ configuration tool
• Flexible mounting and simplified wiring to speed up installation
APPLICATIONS
• Manufacturing
• Shop Floor
• Warehousing
FEATURES & BENEFITS
• Easy, fast, modular connection for ID-NET™Network
• Distribution on separate connectors of Power Supply,
External Trigger, ID-NET™ network, Digital I/O and
Communication signals
• Serial-to-Ethernet TCP/IP protocol conversion through
QL500 module.
• Cost effective solution
• Compact dimensions
The CBX100 and CBX500, part of the CBX series, are a connectivity devices designed to simplify and
speed-up cabling operations during the installation of Datalogic Automation devices. The CBX100’s
modular concept and complete range of module options make installation, configuration and
maintenance faster than ever.
FEATURES & BENEFITS
• Flexible mounting and simplified wiring to speed up installation
• Reliable Backup and Restore features
• Open architecture allows connectivity to Ethernet TCP/IP, PROFIBUS, DeviceNet Ethernet/ IP and other
common networks
• Multilanguage display for easy monitoring and troubleshooting
• Visible led indicators and power on/off switch
