DIMENSIONER
DM3610
DIMENSIONING ACCURACY
• NTEP
• OIML
± 0.2” for length and width and ± 0.1” for height
± 5 mm for length, width and height
MAX CONVEYOR SPEED
up to 3.2m/s
CASE MATERIAL
Aluminum
MAX PARCEL DIMENSIONS
2500 x 1200 x 900 mm (98 x 48 x36 in)
WEIGHT
5.5 kg (12.13 lb)
OVERALL DIMENSIONS
(TYPICAL VALUE)
259 x 152 x 175mm (11 x 6 x 6.9 in)
MOUNTING DIMENSIONS
(TYPICAL VALUE)
340 x 182 x 281mm (13.39 x 7.15 x 11.07 in)
TEMPERATURE RANGE
-10° - 50 °C ( 14 - 122 °F)
VOLTAGE SUPPLY / POWER
CONSUMPTION
24 VDC; 19 -75 W
IP RATING
IP65
EMBEDDED
COMMUNICATION INTERFACES
Ethernet (TCP/IP), RS232 / RS422
DIGITAL INPUTS / OUTPUTS
(1) Tachometer, (1) Trigger, (2) SW programmable general purpose
OPTIONS
Side-by-side package detection, irregulars, out-of-gauge detection
COMPLIANCES
UL, cUL, FCC (Class A) CE
ETHERNET
ü
CERTIFICATION
NCWM/NTEP Certified, OIML/MID, Measurement Canada
DEVICE PROGRAMMING
On board HTML web server interface
