41
LASER
SCANNERS
AL5010
DS6300
DS6400
READING DISTANCE (MIN / MAX)
up to 1200 mm
(47.24 in)
250 - 2000 mm
( 9.84 - 78.74 in )
300 - 2500 mm
(11.81 x 98.43 in )
MAX RESOLUTION
down to 0.18mm (7mils)
down to 0.20mm (8mils)
down to 0.20mm (8mils)
SCAN RATE
up to 1200 scans/s
(SW programmable)
600 - 1200 scans/s
(SW programmable)
600 - 1200 scans/s
(SW programmable)
SCAN PATTERN TYPE
Linear / Oscillating Mirror
Linear / Oscillating Mirror
Linear / Oscillating Mirror
VARIABLE FOCUS
û
ü
ü
APERTURE ANGLE
60 degrees
û
û
MULTILABEL READING
Up to 10 Codes in the same reading phase
Up to 10 Codes in the same reading phase
Up to 10 Codes in the same reading phase
BAR CODE ASSIGNMENT TECHNOLOGY
PACKTRACK™
û
PACKTRACK™
AUTOFOCUS / DYNAMIC FOCUS
û
û
ü
FLASH™
RECONSTRUCTION CODE TECHNOLOGY
DRX
ACR4™
ACR4™
READABLE CODES
All standard 1D symbologies
Code 2/5, Code39, Code93, Code128, EAN/UPC,
EAN128, Codabar, Pharmacode, ISBN128
Code 2/5, Code39, Code93, Code128, EAN/UPC,
EAN128, Codabar, Pharmacode, ISBN128
CASE MATERIAL
Aluminum, high impact plastic
Aluminum
Aluminum
DIMENSIONS (TYPICAL VALUE)
104 x 130.8 x 49.9 mm (4.09 x 5.15 x 1.96 in )
110 x 113 x 99 mm ( 4.33 x 4.45 x 3.9 in )
110 x 113 x 99 mm ( 4.33 x 4.45 x 3.9 in )
WEIGHT
Total Weight
0.69 - 0.79 kg (24,69 oz -27,86 oz)
1.5kg (52.91 oz)
1.5kg (52.91 oz)
TEMPERATURE RANGE
0° - 50 °C (32 - 122 °F)
0° - 40 °C (32 - 104 °F)
0° - 40 °C (32 - 104 °F)
VOLTAGE SUPPLY / POWER
CONSUMPTION
12-30 VDC ; 25W
15-30 VDC; 15-20 W
15-30 VDC; 15-20 W
IP RATING
IP65
IP64 (IP65 on request)
IP64 (IP65 on request)
EMBEDDED
COMMUNICATION INTERFACES
On board EtherNet/IP, Ethernet TCP/IP,
Serial RS 232/RS 422,DeviceNet, Profibus
(See Basic and Enhanced Interface Module
Specification)
Main Port: RS232/RS485 up to 115.2 Kbit/s
Auxiliary Port: RS232 up to 115.2 Kbit/s
Lonworks (Master/Slave), Ethernet, Profibus,
DeviceNet
Main Port: RS232/RS485 up to 115.2 Kbit/s
Auxiliary Port: RS232 up to 115.2 Kbit/s
Lonworks (Master/Slave), Ethernet, Profibus,
DeviceNet
DIGITAL INPUTS
Two Programmable I/O relays
Four SW programmable, optocoupled,
NPN/PNP
Three SW programmable and One "Encoder",
optocoupled, NPN/PNP
DIGITAL OUTPUTS
Two Programmable I/O relays
Three SW programmable, optocoupled,
event driven
Three SW programmable, optocoupled,
event driven
ID-NET™ INTERFACE
û
û
û
FIELDBUS
û
ü
Embedded
ü
Embedded
ETHERNET
ü
Embedded
ü
Embedded
ü
Embedded
XPRESS INTERFACE™
û
û
û
DEVICE PROGRAMMING
On board HTML / HTML5 Web Server interface
Genius™ (Windows™ based) SW
Serial Host Mode Programming sequences
Genius™ (Windows™ based) SW
Serial Host Mode Programming sequences
