MATRIX 300™
2D IMAGERS
MATRIX 210™
The Matrix 210™ is a high-performance, 2D code reader in ultra-compact housing with Ethernet on-board.
The Matrix 210’s WVGA image sensor allows it to capture up to 60 frames per second, while its powerful
internal illuminator results in extremely dynamic reading capability. The unrivalled decoding libraries
running on the new high speed hardware platform result in superior reading robustness and impressive
decoding rates, supporting high system throughput and increasing efficiency. The on-board Ethernet
allows for the transfer of both reading data and captured images that can be easily and quickly uploaded
on external PCs or servers for storage or offline process analysis.
The Matrix 300™ is an ultra-compact, image based code reader purpose built for superior performance
in high-speed and Direct Part Marking (DPM) applications. The Matrix 300™ combines a high resolution
sensor with ultra-fast image acquisition: 1.3 megapixels, 60 frames per second. The optical system
incorporates a liquid lens module for electronic focus control. As a result, the reader offers automatic
focus adjustment with no additional moving parts.
APPLICATIONS
F
actory
A
utomation
A
pplications
Electronics:
Pick and Place Machines, DPM
Reading and Code Quality Verification, WIP Control,
Test Tracking, Component Traceability, Parts
Traceability and Control
Automotive:
DPM Reading and Code Quality
Verification, WIP Control, Parts Traceability
Tires:
Curing Process Control, Labeling Verification
Food & Beverage:
Label Print and Check, Product
Traceability
Pharmaceutical:
Primary Package Verification,
Track and Trace
Warehousing:
Tote Tray Identification, Automatic
Picking Process Control, Print & Labeling Process
OEM A
pplications
Specimen collection machines, clinical lab
automation machines
FEATURES & BENEFITS
• Direct and 90° window models for smart
mounting
• X-PRESS™ for easy and intuitive setup
• Optical aiming system
• Internet, serial, USB connectivity
• ID-NET™ embedded for high speed connectivity
• Region of interest window for higher frame rate
• Run-time self tuning for higher flexibility
APPLICATIONS
F
actory
A
utomation
A
pplications
Electronics:
Pick and Place Machine, DPM Reading
and Code Quality Verification, WIP Control,
Test Tracking, Component Traceability, Parts
Traceability and Control
Automotive:
DPM Reading and Code Quality
Verification, Traceability for Manual Assembly, WIP
Control, Parts Traceability
Tires:
Curing Process Control, Labeling Verification
Food & Beverage:
Label Print and Check, Shipping
Process, Product Traceability
Pharmaceutical:
Secondary Package Control,
Primary Package Verification, Track and Trace
Warehousing:
Tote Tray Identification,
Identification for Manual Induction Stations,
Automatic Picking Process Control, Print &
Labeling Process Verification
OEM A
pplications
Specimen collection machines, clinical lab
automation machines
FEATURES & BENEFITS
• Integrated dual illuminator: dark field/bright field
• Power over Ethernet Option
• Extreme Industrial grade: IP67, 0-50°C operating
temperature
• Precise dual laser aiming system
