LASER SCANNERS
DS6300
The high-performing DS6300 industrial laser bar code scanner features the new Step-a-Head™
functionality, including “2-step’ optics, as well as a reading range from 250 to 2.000 mm, an advanced
decoder with code reconstruction capability (ACR4), strong reading performance on very low contrast bar
codes, a display and keyboard, and the new GENIUS™ SW configurator.
APPLICATIONS
F
actory
A
utomation
A
pplications
Automotive:
WIP Control, Parts Traceability
Food & Beverage:
Shipping Process, End of Line
Palletizing
Pharmaceutical:
Secondary Package Control
T
ransportation
and
L
ogistics
A
pplications
Picking Systems, pallet reading
FEATURES & BENEFITS
• Selectable focus system
• Avalanche photodiode technology
• 600-1200 scan /sec
• 4 inputs + 3 outputs
• Built in Ethernet, PROFIBUS or Devicenet
• ACR4 decoding algorithm
• Typical reading range: 300 - 1400mm
DS6400
The DS6400 is a high performance industrial laser bar code scanner highlighted by the Step-a-Head™
feature, a reading range from 300 to 2.500mm, FLASH™ dynamic focus, an advanced decoder with code
reconstruction capability (ACR4), the GENIUS™ SW configurator and PackTrack™ technology.
APPLICATIONS
F
actory
A
utomation
A
pplications
Automotive:
WIP Control, Parts Traceability
Food & Beverage:
Shipping Process, End of Line
Palletizing
Pharmaceutical:
Secondary Package Control
Warehousing:
Sorting and Shipping Process
T
ransportation
and
L
ogistics
A
pplications
Parcel sorting
FEATURES & BENEFITS
• Dynamic focus system (FLASH™)
• Avalanche photodiode technology
• 600-1200 scan /sec
• 4 input + 3 output
• RS232 + RS485 serial port
• Built in Ethernet or PROFIBUS or Devicenet
• ACR4 decoding algorithm
• Typical reading range: 500 x 2000 mm
AL5010
The AL5010 is a high performance industrial laser scanner with cutting edge integrated control
technology that meets demands of current and new automated facilities. With 1200 scans per second,
the AL5010 can solve challenging applications, including extremely high transport speeds or small bar
codes. With its rugged construction, IP65 protection class, 50°C maximum operating temperature and
internal oscillating mirror, the AL5010 is purpose built for the most demanding industrial environments.
APPLICATIONS
F
actory
A
utomation
A
pplications
Automotive:
WIP Control, Parts Traceability
Food & Beverage:
Shipping Process, End of Line
Palletizing
Pharmaceutical:
Secondary Package Control
T
ransportation
and
L
ogistics
A
pplications
Picking Systems, pallet reading
FEATURES & BENEFITS
• Largest depth of field of any mid-range laser bar
code reader on the market
• PackTrack™ advanced tracking allows closer
package spacing while maintaining package ID
• Integrated web server with monitoring support
for iPhone and iPads
• Multi-language integrated GUI
• Easy “plug and play” replacement
• Flexible connectivity with on board EtherNet/IP,
Ethernet TCP/IP
• Reliability > 50,000 hours MTBF at 25C
• No maintenance
