MATRIX 450™
2D IMAGERS
MATRIX 410™
The Matrix 410™ is a modular, versatile and compact 2D bar code reader for industrial applications with
embedded 1.3 and 2.0 megapixel sensors. The Matrix 410™ offers excellent performance in bar code
reading and verification applications, as well as easy setup with its X-PRESS™ interface and patented
Blue Diamonds™ system.
The MATRIX 450™ is a high-end, industrial 2D reader designed for transportation and logistics applications.
With an extraordinary acquisition rate at very high resolution and a high intensity illuminator, the Matrix
450™ is the ideal product for automated and material handling. Through its 5 million pixels captured 15
times second, the MATRIX 450™ can be implemented in a range of applications never before solved by a
2D Imager. This 2D reader provides a large reading area in a single shot, resulting in high throughput and
maximum ease of use – eliminating the need for multiple reading attempts.
APPLICATIONS
F
actory
A
utomation
A
pplications
Electronics:
DPM Reading and Code Quality
Verification, WIP Control, Test Tracking, Component
Traceability, Parts Traceability and Control
Automotive:
DPM Reading and Code Quality
Verification, Traceability for Manual Assembly, WIP
Control, Parts Traceability
Tires:
Final Inspection, Sorting & Shipping, Final
Finishing and Inspection, Curing Process Control,
Labeling Verification
Food & Beverage:
Shipping Process, Product
Traceability
Pharmaceutical:
Secondary Package Control,
Primary Package Verification, Track and Trace
Warehousing:
Tote Tray Identification,
Identification for Manual Induction Stations,
Automatic Picking Process Control, Print &
Labeling Process Verification
FEATURES & BENEFITS
• C-Mount lens
• Red and white LED illuminators
• Pointing system and good read spot
• DPM code reading
• Code quality verification
APPLICATIONS
F
actory
A
utomation
A
pplications
Electronics:
DPM Reading and Code Quality
Verification, WIP Control, Test Tracking, Component
Traceability, Parts Traceability and Control
Automotive:
DPM Reading and Code Quality
Verification, Traceability for Manual Assembly, WIP
Control, Parts Traceability
Tires:
Final Inspection, Sorting & Shipping, Final
Finishing and Inspection, Curing Process Control,
Labeling Verification
Food & Beverage:
Shipping Process, Product
Traceability
Pharmaceutical:
Secondary Package Control,
Primary Package Verification, Track and Trace
Warehousing:
Tote Tray Identification,
Identification for Manual Induction Stations,
Automatic Picking Process Control, Print &
Labeling Process Verification
FEATURES & BENEFITS
• Gigabit Ethernet integrated connectivity
• Adjustable focus through C-Mount lenses
• White and blue lighting options
• Continuous, no-flashing lighting
• Colored spot indicators
• Region of interest window for higher frame rate
• X-PRESS™ for easy and intuitive setup
• ID-NET™ embedded high speed connectivity
