2D IMAGERS
MATRIX 210™
MATRIX 300™
READING RANGE (MIN - MAX)
30 - 190 mm
(1.2 - 7.5 in)
25 - 450 mm
(1.2 - 19.7 in)
FOCUSING SYSTEM
Fixed focus position
Electronic for liquid lens model (LQL-9MM)
SENSOR
CMOS sensor with Global Shutter
WVGA - 752x480
CMOS sensor, Global Shutter
SXGA - 1280x1024 - 1.3 MP
FRAME RATE
60 frames/s @full window size
60 frames/s @full window size
ON BOARD MEMORY
128 MB
256 MB
READABLE CODES
1D Codes: all standard 1 dimensional symbologies
2D Codes: Data Matrix, QR Code, Micro QR, Maxicode, Aztec
Postal Codes: Royal Mail, Japan Post, Planet, Postnet and many more
1D Codes: all standard 1 dimensional symbologies
2D Codes: Data Matrix, QR Code, Micro QR, Maxicode, Aztec
Postal Codes: Royal Mail, Japan Post, Planet, Postnet and many more
CODE ORIENTATION
Omnidirectional on any code type
Omnidirectional on any code type
MULTILABEL/MULTICODE READING
ü
ü
VOLTAGE SUPPLY / POWER
CONSUMPTION
5-30 VDC; 2.5 - 4.5 W
Std 5-30 VDC
PoE 48 VDC; 5 - 8 W
IP RATING
IP65
IP67
TEMPERATURE RANGE
0 to 50 °C (32 to 122 °F)
0 to 50 °C (32 to 122 °F)
CASE MATERIAL
Aluminum alloy
Aluminum, Plastic protective window cover
DIMENSIONS (TYPICAL VALUE)
54 x 32 x 45 mm (2.12 x 1.26 x 1.77 in)
95 x 54 x 43 mm (3.74 x 2.13 x 1,69 in)
WEIGHT
190 g (6.7 oz.) with cable
485g (17 oz.) with lens and internal illuminator
ESD SAFE
ü
ü
YAG LASER PROTECTION
ü
ü
EMBEDDED
COMMUNICATION INTERFACES
RS232/RS422/RS485
USB 2.0 in RS232 MODE
Ethernet 10/100
RS232/RS422/RS485
Ethernet 10/100
ID-NET™ INTERFACE
ü
ü
FIELDBUS
ü
Profinet I/O Embedded
Additional fielbus available with CBX & QLM accessories
ü
Profinet I/O Embedded
Additional fielbus available with CBX & QLM accessories
ETHERNET
ü
Embedded
ü
Embedded
XPRESS™ INTERFACE
ü
ü
DIGITAL INPUTS
Two opto-isolated. Polarity insensitive and SW Programmable.
Two opto-isolated. Polarity insensitive and SW Programmable.
DIGITAL OUTPUTS
Two SW programmable optocoupled
Three SW programmable PNP/NPN (short circuit protection)
OUT3 programmable as input too
DEVICE PROGRAMMING
VisiSet™ setup SW (Windows™ based)
String programming Interface
VisiSet™ setup SW (Windows™ based)
String programming Interface
