LASER SCANNERS
DS1100
APPLICATIONS
F
actory
A
utomation
A
pplications
Electronics:
WIP Control, Test Tracking, Parts
Traceability and Control
Automotive:
WIP Control, Parts Traceability
Food & Beverage: Label Print and Check
Pharmaceutical:
Primary Package Verification,
Track and Trace
OEM A
pplications
Biomedical analysis machines, Automatic Teller
Machines
The DS100 embedded bar code reader is a cost-effective laser scanner characterized by ultra-compact
dimensions, motor on/off software commands, wide reading width at a short reading distance,
lightweight design (<100 g), built-in RISC decoder, scanning speed of 500scans/sec, dual high speed serial
interface, and IP65 rugged industrial housing.
FEATURES & BENEFITS
• Straight and 90°output window
• 2 inputs + 2 outputs
• RS232 + RS485 serial port
• Winhost programming tool
• Typical reading range of 50 - 200mm
DS1500
APPLICATIONS
F
actory
A
utomation
A
pplications
Electronics:
Pick and Place Machine, WIP Control,
Test Tracking, Parts Traceability and Control
Automotive:
WIP Control, Parts Traceability
Food & Beverage: Label Print and Check
Pharmaceutical:
Primary Package Verification,
Track and Trace
Warehousing:
Print & Labeling Process Verification
OEM A
pplications
Packaging machines, biomedical analysis
machines, document handling machines
The combination of extremely compact dimensions and powerful high speed reading capabilities makes
the DS1500 scanner ideal for demanding OEM applications. The miniature size of the DS1500 allows for
easy integration into OEM equipment and automatic machinery. The high scan rate and sophisticated
electronic design ideal for difficult reading conditions.
FEATURES & BENEFITS
• Scan Frequency: 800-1200scan/sec
• 1 input + 2 outputs
• RS232 + RS232 or RS485 serial port
• Typical reading range of 50 – 200mm
DS2200
APPLICATIONS
F
actory
A
utomation
A
pplications
Electronics:
Pick and Place Machine, WIP Control,
Test Tracking, Parts Traceability and Control
Automotive:
WIP Control, Parts Traceability
Food & Beverage:
Label Print and Check
Pharmaceutical:
Primary Package Verification,
Track and Trace
Warehousing:
Print & Labeling Process Verification
OEM A
pplications
Biomedical analysis machines, document handling
machines
The DS2200 embedded bar code scanner is an ultra-compact laser scanner with a built-in decoder,
that can perform 500 scans per second at a reading distance ranging from 50 to 220 mm.
DS2200 scanner is a cost effective solution for OEM applications.
FEATURES & BENEFITS
• Excellent reading capabilities
• Purpose-built for OEM integration
• Very high density code reading
(up to 0.076 mm / 3 mils)
