INDUSTRIAL
HANDHELD
DEVICES
PowerScan™ 9500 Series
PowerScan™ PD8590-DPM
PowerScan™ 8300 Series
READING DISTANCE (MIN / MAX)
0 to over 1m (0 to over 39.4 in)
depending on code resolution
0 to 5.1 cm (0 to 2.0 in)
0 to over 12 m (0 to over 39.4 ft) depending on
code resolution
SENSOR
CMOS sensor SXGA (1280x1024) 1.3 MP
CMOS sensor SXGA (1280x1024) 1.3 MP
Laser
SCAN RATE
60 scan/sec
•
35 scan/sec
VARIABLE FOCUS
Liquid lens autofocus system
•
•
READING ANGLE
Pitch: +/- 40°; Roll (Tilt): 360°; Skew (Yaw):
+/- 40°
Pitch: ±30° Skew: ±30° Rot.Tolerance: ±180°
Pitch: 5 to 55° / -5 to -55°; Roll
(Tilt): +/- 20°; Skew (Yaw): +/-60°
MULTILABEL READING
Yes
No
No
READABLE CODES
1D / Linear Codes: autodiscriminates all
standard 1D codes including GS1 DataBar™
linear codes, 2D Codes Aztec Code; China Han
Xin Code; Data Matrix; MaxiCode; Micro QR Code;
QR Code, Postal Codes Australian Post; China
Post; IMB; Japanese Post; KIX Post; Planet Code;
Portuguese Post; Postnet; Royal Mail, Code
(RM4SCC); Swedish Post, Stacked Codes, EAN/
JAN Composites: GS1 DataBar Composites;
GS1 DataBar Expanded Stacked; GS1 DataBar
Stacked; GS1 DataBar Stacked Omnidirectional;
MacroPDF; MicroPDF417; PDF417; UPC A/E
Composites
2D Codes: Data Matrix, QR Code,Micro QR Code
STACKED Codes:PDF417, GS1 Databar
(Composite & Stacked)
1D or Linear Codes: Code 39, Code 128, I2 of 5,
UPC/EAN, Codabar, Code 93, BC 412
1D / Linear Codes: autodiscriminates all
standard 1D codes including GS1 DataBar™
linear codes. Stacked Codes: Code 16K; Code 49;
GS1 DataBar Expanded Stacked; GS1 DataBar
Stacked; GS1 DataBar Stacked Omnidirectional
CASE MATERIAL
ABS
ABS
ABS
DIMENSIONS (TYPICAL VALUE)
212 x 110 x 74 mm (8.3 x 4.3 x 2.9 in)
180 x 63 x 114 mm (7.09 x 2.48 x 4.49 in)
207 x 114 x 69 cm (8.1 x 4.5 x 2.7 in)
WEIGHT
330.0 g (11.6 oz)
204 g (7.2 oz) not including cable
295.0 g (10.4 oz)
TEMPERATURE RANGE
Operating: -20 to 50 °C / -4 to 122 °F
0 to 50 °C (32 to 122 °F)
Operating: -30 to 50 °C / -22 to 122 °F
VOLTAGE SUPPLY
/ CURRENT ABSORPTION
5 VDC +/- 10%; 335 mA (operating typical)
5 VDC ; 500mA
4 - 30 VDC / Operating (typical): D8330: 420
mA@ 4 V; 310 mA@ 5 V; 62 mA@30 V
IP RATING
IP65
--
IP65
MODELS (OPTIC OPTIONS)
HP (liquid lens autofocus); DPM
--
Standard, Autorange
MODELS (COMMUNICATION OPTION)
Corded, Cordless
(Datalogic STAR Cordless System)
Corded only
Corded, Cordless
(Datalogic STAR Cordless System)
EMBEDDED
COMMUNICATION INTERFACES
USB,RS232, KBD emulation
(+ Ethernet on the cordless model)
USB, RS232
USB, RS232, KBD emulation
RADIO RANGE (CORDLESS MODELS)
up to 100 m (open air)
--
up to 50 m (open air)
ETHERNET
On the cradle for the cordless model
•
•
DEVICE PROGRAMMING
barcode, Aladdin
barcode, ESP (Easy Setup Program)
barcode, Aladdin
