2D IMAGERS
MULTIPLE HEADS
SOLUTIONS
STS 400™- Passenger Light Truck Tires
STS 400™- Commercial Vehicle Tires
READING DISTANCE (MIN / MAX)
890 - 1140 mm
(35 - 44.9 in)
880 - 1280 mm
(34.6 - 50.4 in)
READING WIDTH mm (inch) n° 6
HEADS
945 mm ( 37.2 in)
945 mm ( 37.2 in)
READING WIDTH mm (inch) n° 7
HEADS
1085 mm (42.7 in)
1085 mm (42.7 in)
READING WIDTH mm (inch) n° 8
HEADS
1225 mm (48.2 in)
1225 mm (48.2 in)
SENSOR
CCD sensor UXGA (1600x1200) 2 MP
CCD sensor UXGA (1600x1200) 2 MP
FRAME RATE
15 frames / s
15 frames / s
MAX RESOLUTION
0.30mm (12 mils)
0.35mm (14 mils)
READABLE CODES
1D and Stacked: IL 2/5, Code 128, Code 39, Code 32, MSI, Std 2 of 5,
Matrix 2 of 5, Interleaved 2 of 5, Codabar, Code 93, EAN/UPC,
PDF417, Micro PDF417, Pharmacode,
GS1 DataBar (RSS) family, Composite Symbologies
2D: Data Matrix ECC200, QR Code, Micro QR, Maxicode, Aztec Code
Postal: Australia Post, Royal Mail 4 State Customer, Kix Code,
Japan Post, Planet, Postnet, Intelligent Mail, Swedish Post
1D and Stacked: IL 2/5, Code 128, Code 39, Code 32, MSI, Std 2 of 5,
Matrix 2 of 5, Interleaved 2 of 5, Codabar, Code 93, EAN/UPC,
PDF417, Micro PDF417, Pharmacode,
GS1 DataBar (RSS) family, Composite Symbologies
2D: Data Matrix ECC200, QR Code, Micro QR, Maxicode, Aztec Code
Postal: Australia Post, Royal Mail 4 State Customer, Kix Code,
Japan Post, Planet, Postnet, Intelligent Mail, Swedish Post
CODE ORIENTATION
Omnidirectional on any code type
Omnidirectional on any code type
MULTILABEL/MULTICODE
READING
ü
ü
VOLTAGE SUPPLY / CURRENT
ABSORPTION
24 VDC ; 1.35 A
24 VDC ; 1.71 A
IP RATING
IP65
IP65
TEMPERATURE RANGE
0 - 50 °C ( 32 - 122 °F)
0 - 50 °C ( 32 - 122 °F)
CASE MATERIAL
Aluminum
Aluminum
ARRAY OVERALL DIMENSIONS
(TYPICAL VALUE)
STS400-006
: 785 x 223 x 149 mm (30.91 x 8.78 x 5.87 in.)
STS400-106
: 800 x 241 x 176 mm (31.50 x 9.49 x 6.93 in)
WEIGHT
STS400-006
: 10 kg (22.05 lb)
STS400-106
: 10 kg (22.05 lb)
EMBEDDED
COMMUNICATION INTERFACES
RS232/RS422/RS485
Ethernet IEEE 802.3 10 Base T and IEEE 802.3U
100 BaseTX compliant
RS232/RS422/RS485
Ethernet IEEE 802.3 10 Base T and IEEE 802.3U
100 BaseTX compliant
ID-NET™ INTERFACE
ü
ü
FIELDBUS
ü
Available with external device
ü
Available with external device
ETHERNET
ü
Embedded
ü
Embedded
XPRESS INTERFACE™
ü
ü
DIGITAL INPUTS
Input 1 (External Trigger)
Input 2 Opto-coupled and polarity insensitive
Input 1 (External Trigger)
Input 2 Opto-coupled and polarity insensitive
DIGITAL OUTPUTS
Output 1 and Output 2 Opto-coupled
Output 1 and Output 2 Opto-coupled
DEVICE PROGRAMMING
VisiSet™ setup SW (Windows™ based)
Serial Host Mode Programming sequences
VisiSet™ setup SW (Windows™ based)
Serial Host Mode Programming sequences
